PDC Status
PDC Status
Power delivery control? or cotract? It’s green even when the DUT is not plugged in. What is this excactly.
Green light for the DUT attached indicates that the DUT is plugged in. E-marked shows that the cable used is a E-marked cable. For more information on E-Marked click here.
- What is the difference between detach, reconnect, reset and assert, deassert, pulse hpd?
- Is CC1 straight and CC2 flipped?
The last information on this panel is the cable orientation. You can flip the cable orientation from straight (CC1) to flipped (CC2) and vise versa by selecting the desired option and pressing reconnect. . As this is done the cable orientation status changes to flipped as seen in the gif below:
